SLM-6M 2 Maginifications Portable and Economic Slit Lamp Microscope

SLM-6M FREE shipping 2 Maginifications Portable and Economic Slit Lamp Microscope

SLM-6M portable slit lamp:

1. 2 magnifications (10x, 16x)

2. Changing magnification by rotating objective lens ( patent)

3. With 10x eyepiece

4. With Li-ion battery and battery charger

5. With metal case

6. With Focus sticks and Forehead bracket.

High-brightness LED, cold-light illuminator, brightness up to 30000 LUX, service life more than 50000 hours.

Sharp slit, the width can be adjusted continuously. Telescopic forehead-rest is easier to observe and adjust the diopter.

Easier to adjust the magnification by resolvable objective lens.

Small and light, only 700g including battery.

Different filters:Heat

Absorption;Yellow;Redfree(Green);Cobalt Blue.

Full power supplied by battery can drive the slit lamp for 5-6 hours.

Two magnifications for using. Easy to take for a doctor

Feature:

1.Portable slit lamps are used for the examination of the anterior segment in Human and Veterinary medicine.

2.They are compact and light-weight and ideal for situations where a full-size slit lamp is not available or convenient

3.Perfect optical alignment,will provide a lifetime of reliable performance.

4.Excellent optics maximize light transmission and reduce reflexes

5.Portable slit lamps are used for the examination of the anterior segment in Human and Veterinary medicine.

6.They are compact and light-weight and ideal for situations where a full-size slit lamp is not available or convenient

7.Perfect optical alignment,will provide a lifetime of reliable performance.

8.Excellent optics maximize light transmission and reduce reflexes

9.Compact design for portability and ease of use

10.100% dustproof construction for a lifetime of maintenance-free performance

Magnifications:

Item / Model		SLM-6L	SLM-6M	SLM-6H
Microscope	Type	Converging
	Objective Lens	1.0×	1.0× 1.6×	1.0×,1.6x
	Eyepiece	10x	10x	10x ,16x
	Total Magnifications	10×	10×,16x	10× ,16×,25x
	Working Distance	81mm
	Intraocular Distance	45mm-78mm
	Diopter Adjustment	-8D ~ +8D
Illumination	Slit Width	0-12mm Continusous
	Slit Height	1~12mm	1~12mm	1~12mm
	Slit Angle	Horizontal+30°
	Illumination fields Ø in mm	Φ12mm	Φ0.2mm ;Φ1mm; Φ5mm; Φ12mm
	Filters	Heat absorption; Yellow; Redfree (Green); Cobalt Blue
	Light source	High-Brightness White LED
	Brightness	>30000Lux
	Power	5VA
Power	Voltage	AC100~240V, 50/60Hz
	LED Working Voltage	DC 3V, 350mAh
	Battery	Li-ion Battery; 7.4V, 680mAh, Full Battery can supply 5-6 hours continuously
Weight and Dimension	Dimension	169.5 ×109.5 ×228.5mm
	Weight	700g (Including Battery)
